Inner Climbing Luffing Tower Crane
QTD 5020 Inner Climbing Luffing Tower Crane
Inner Climbing Luffing Tower Crane QTD 5020 with maximum load capacity of 8tons or 10tons, Jib length of 50m with tip load 2tons Mast size: 2x2x3m and 1.6x1.6x3m
Luffing Jib Tower Crane
HSH can supply the luffing jib tower crane with max.load from 6tons to 20tons. The luffing jib tower cranes are very popular especially in the south-east Asian countries. Luffing jib tower cranes are characterized by high height under hook, and small working radius on the counter jib, which are suitable for the working in the very narrow area, and dense buildings or more cranes working at the same site simultaneously. Through the pitch working of the jib, the interference under many tower cranes working together can be avoided effectively.
Main Specifications
Model | QTD5020 | |
Max Load | 8/10tons | |
Tip Load | 2tons | |
Jib Length | 50m | |
Free Standing Height | Stationary | 38.1m |
Mechanisms | Hoisting Speed (m/min) | (a=2) 0-45m/min: 5t; 0-90m/min: 2.5t |
Luffing (min) | <=3.0min | |
Slewing Speed (r/min) | 0~0.7r/min | |
Power | Hoisting (KW) | 45KW |
Luffing (KW) | 30KW | |
Slewing (KW) | 2*4.5KW | |
MAST: 2x2x3m / 1.6x1.6x3m
